Reina Eos Curved Stainless Steel Designer Radiator Polished

Reina Logo
More Variations Available
No Rating No Rating Write a Review
Rate This:
MFC Code : RNS-ES5043
Product Code : 9273
Delivery: £34.95
£158.03
RRP : £228.00
SELECT Width Step 1

SELECT Height Step 2

SELECT Radiator Type Step 3

SELECT Heating Elements Step 4

SELECT Essential Accessories Step 5


qty :

Check Availability 5 Working Days Apprx
Chrome Pipe Kit
Accessories

Reina provides an optional Chrome Pipe Kit that you may require for the installation. These kit are highly recommended from the manufacturer. Please note: Image shown is for illustration purpose only.



About This Product

  • Available in different widths: 500mm and 600mm - [See Option]
  • Availalbe in different heights: 430mm, 720mm, 1200mm and 1500mm - [See Option]
  • Available in different variants: Central heating, Dual Fuel and Electric - [See Option]
  • Choice of heating elements available - [See Option]
  • Finish: Polished
  • Material: Stainless steel
  • Wall to pipe centres: 50-60mm (5-6cm)
  • Distance from wall: 75-85mm (7.5-8.5cm)
  • Brackets for radiator included
  • Supplied with Air vent and End plug
  • EN 442 Compliant Product
  • The valves shown in the image are not included
  • For BTU and Watts, Please Refer to the Chart in the Product Variations Info & MFC Code section
  • For more information on Elements, options download the Elements PDF File from the Technical Info Section
  • Refer to the technical diagram for complete technical dimensions
  • Guarantee: Twenty-five-year from Reina against manufacturing defects
  • Available Optional Product:
  • Sleeving kit and chrome pipe kit
  • Compatible Valves
  • T-Piece - For Dual Fuel Only
  • Liquid Filling For Electric Only
  • Please Note:
  • The appropriate wattage of the element (if selected) will be decided by the manufacturer, once the order is placed.

Information Breakdown

Colour Polished
Country of Origin UK
Warranty/Guarantee 25 Years,25 Years
Theme Modern
Material Stainless Steel,Stainless Steel
Width 500
Height 430
Orientation Vertical
BTU Output 970
Watts 284
Tapping / Pipe Centres 468
Valves Included Sold Separately
Fuel Type Central Heating | Dual Fuel | Electric
Wall to Centre of Inlet 50-60
Heating Element Included Sold Separately
Brackets Included Yes
Installation Type Wall Mounted

Technical Info


PRODUCT VARIATIONS INFO & MFC CODE
  • Specification For 500mm Curved Designer Radiator
    Variants Height - 430mm Height - 720mm Height - 1200mm Height - 1500mm
    Fuel Type Central Heating / Electric / Dual Fuel Central Heating / Electric / Dual Fuel Central Heating / Electric / Dual Fuel Central Heating / Electric / Dual Fuel
    Width 500mm 500mm 500mm 500mm
    Finish Polished Polished Polished Polished
    Pipe Centres 500mm 500mm 500mm 500mm
    Wall To Pipe Centre 50-60mm 50-60mm 50-60mm 50-60mm
    Wall Distance 75-85mm 75-85mm 75-85mm 75-85mm
    Tube Quantity 6 10 16 20
    Total Gap 1 1 2 3
    Watts - Delta-70 284 567 780 1039
    BTU - Delta-70 970 1935 2660 3544
    BTU - Delta-60 795 1586 2180 2905
    BTU - Delta-50 626 1248 1716 2286
    BTU - Delta-45 545 1087 1494 1991
    BTU - Delta-40 471 939 1291 1720
    BTU - Delta-35 394 787 1081 1441
    BTU - Delta-30 320 639 878 1170
    BTU - Delta-25 125 249 342 456
    MFC RNS-ES5043 RNS-ES5072 RNS-ES5120 RNS-ES5150
  • Specification For 600mm Curved Designer Radiator
    Variants Height - 430mm Height - 720mm Height - 1200mm Height - 1500mm
    Fuel Type Central Heating / Electric / Dual Fuel Central Heating / Electric / Dual Fuel Central Heating / Electric / Dual Fuel Central Heating / Electric / Dual Fuel
    Width 500mm 500mm 500mm 500mm
    Finish Polished Polished Polished Polished
    Pipe Centres 600mm 600mm 600mm 600mm
    Wall To Pipe Centre 50-60mm 50-60mm 50-60mm 50-60mm
    Wall Distance 75-85mm 75-85mm 75-85mm 75-85mm
    Tube Quantity 6 10 16 20
    Total Gap 1 1 2 3
    Watts - Delta-70 325 612 928 1099
    BTU - Delta-70 1109 2088 3166 3749
    BTU - Delta-60 909 1711 2595 3073
    BTU - Delta-50 715 1347 2043 2419
    BTU - Delta-45 623 1173 1779 2106
    BTU - Delta-40 538 1014 1537 1820
    BTU - Delta-35 451 849 1287 1524
    BTU - Delta-30 366 689 1045 1237
    BTU - Delta-25 143 268 407 482
    MFC RNS-ES6043 RNS-ES6072 RNS-ES6120 RNS-ES6150
  • Specification For Heating Elements
    Variants MFC
    Standard Heating Element ELM/S
    On/Off Touch Element ELMOOT
    LST Mini Round Thermostatic Element ELMMRNLST
    Mini Round Thermostatic Element ELMMRN
    Touch Thermostatic Heating Element ELMTCH
    LST Weekly Thermostatic Element ELMWKYLST
    Weekly Thermostatic Element ELMWKY
  • Specification For Accessories
    TYPE MFC
    T-Piece - For Dual Fuel Only ACCS/TP
    Liquid Filling For Electric Only A/FILLING1
