Name: Reina Deno Stainless Steel Designer Radiator 500 x 496mm
Brand: Reina
SKU: RNS-DE505P
Price: 194.88 GBP
Availability: InStock

About This Product

Available in different variants: Central Heating, Dual Fuel and Electric - [See Option]
Choice of Heating Elements: Standard, On/Off Touch, Thermostatic: LST Mini Round, Mini Round, Touch, LST Weekly and Weekly - [See Option]
Dimensions: Width 500mm (50cm) x Height 496mm (49.6cm)
Material: Stainless steel
Pipe centres: 460mm (46cm)
Wall to pipe centres: 47-62mm (4.7-6.2cm)
Wall distance: 85-100mm (8.5-10cm)
Brackets for radiator included
Supplied with Air vent and End plug
EN 442 Compliant Product
The valves shown in the image are not included
For BTU and Watts, Please Refer to the Chart in the Product Variations Info and MFC Code section
For more information on Elements options download the Elements PDF File from the Technical Info Section
Refer technical drawing for more details
Guarantee: Twenty-five-year from Reina against manufacturing defects
Available Optional Product:
Sleeving kit and chrome pipe kit
Compatible Valves
T-Piece - For Dual Fuel Only
Liquid Filling For Electric Only
Please Note:
The appropriate wattage of the element (if selected) will be decided by the manufacturer, once the order is placed.

Information Breakdown

Colour	Polished
Warranty/Guarantee	25 Years
Width	500
Orientation	Vertical
BTU Output	850
Watts	249
Tapping / Pipe Centres	450
Valves Included	Sold Separately
Wall to Centre of Inlet	47-62
Brackets Included	Yes
Installation Type	Wall-Mounted

Compatible Valves

Technical Info

Reina Deno Stainless Steel Designer Radiator 500 x 496mm

Download Heating Elements PDF

Download Heating Element Manual Instructions PDF

PRODUCT VARIATIONS INFO & MFC CODE

Specification For Designer Radiator

Height	496mm
Fuel Type	Central Heating / Electric / Dual Fuel
Width	500mm
Finish	Polished
Pipe Centres	460mm
Wall To Pipe Centre	47-62mm
Wall Distance	85-100mm
Tube Quantity	4
Total Gap	3
Watts - Delta-70	249
BTU - Delta-70	850
BTU - Delta-60	697
BTU - Delta-50	548
BTU - Delta-45	478
BTU - Delta-40	413
BTU - Delta-35	346
BTU - Delta-30	281
BTU - Delta-25	109
MFC	RNS-DE505P

Specification For Heating Element

Variants	MFC
Standard Heating Element	ELM/S
On/Off Touch Element	ELMOOT
LST Mini Round Thermostatic Element	ELMMRNLST
Mini Round Thermostatic Element	ELMMRN
Touch Thermostatic Heating Element	ELMTCH
LST Weekly Thermostatic Element	ELMWKYLST
Weekly Thermostatic Element	ELMWKY

Specification For Accessories

TYPE	MFC
T-Piece - For Dual Fuel Only	ACCS/TP
Liquid Filling For Electric Only	A/FILLING1
