Reina Coneva Horizontal Mild Steel Designer Radiator 550mm High

Reina Logo
More Variation Available
No Rating No Rating Write a Review
Rate This:
MFC Code : RND-CNV05044W
Product Code : 65064
Delivery: £34.95
£149.76
RRP : £227.41
SELECT FINISH Step 1

SELECT Width Step 2

SELECT Radiator Type Step 3

SELECT Heating Element Step 4

SELECT Essential Accessories Step 5

qty :
Compatible Valves Read More About the Product
Questions Ask Technical Question?
Reviews Write a Review
Check Availability 5 Working Days Apprx

Options & Accessories: You May Require

Chrome Pipe Kit
Accessories

Reina provides an optional Chrome Pipe Kit that you may require for the installation. These kit are highly recommended from the manufacturer. Please note: Image shown is for illustration purpose only.



About This Product

  • Choice of Finishes: White and Anthracite
  • Choice of Widths: 440mm, 580mm, 790mm, 1000mm, 1210mm and 1420mm
  • Choice of Variants: Central Heating, Dual Fuel and Electric
  • Choice of Heating Elements: Standard, On/Off Touch, Thermostatic: LST Mini Round, Mini Round, Touch, LST Weekly, Weekly, Wireless Programmable Thermostat and Square Thermostatic Wifi
  • Horizontal designer radiator
  • Material: Mild steel
  • Height: 550mm (55cm)
  • Wall to Pipe Centres: 68mm (6.8cm)
  • Distance from Wall: 113mm (11.3cm)
  • Supplied with an air vent and end plug
  • Brackets for the radiator included
  • EN 442 Compliant Product
  • The valves and chrome pipes shown in the image are not included
  • For the dual fuel and electric model, heating elements are highly recommended in combination with a T-piece
  • For electric models, optional liquid filling is required with the heating element
  • For BTU and Watts, please refer to the chart in the PRODUCT VARIATIONS INFO and MFC CODE section
  • Download the Data Sheet and Installation Guide PDF File from the Technical Info Section
  • Download the Heating Element and Manual Instructions PDF File from the Technical Info Section
  • Refer to the technical drawing for more specifications
  • Guarantee: Five-year from Reina against manufacturing defects
  • Please Note:
  • The appropriate wattage of the element (if selected) will be decided by the manufacturer once the order is placed
  • Available Optional Product:
  • T-Piece - For Dual Fuel Only
  • Liquid Filling For Electric Only
  • Compatible Valves
  • Sleeving kit and chrome pipe kit

Information Breakdown

Colour White
Warranty/Guarantee 5 Years
Material Mild Steel
Width 440
Height 550
Orientation Horizontal
BTU Output 50°C - 2070
Watts 50°C - 607
Tapping / Pipe Centres 440
Valves Included Sold Separately
Fuel Type Central Heating | Electric | Dual Fuel
Wall to Centre of Inlet 68
Heating Element Included Sold Separately
Element Type Standard | Thermostatic
Brackets Included Yes
Installation Type Wall Mounted
Compatible Valves

Technical Info

Reina Coneva Horizontal Mild Steel Designer Radiator 550mm High

Download Technical Data Sheet PDF

Download Installation Guide PDF

Download Specification For Heating Elements PDF

Download Heating Element Manual Instructions PDF


PRODUCT VARIATIONS INFO & MFC CODE
  • Specification For White Radiator
    Width 440mm 580mm 790mm 1000mm 1210mm 1420mm
    Fuel Type Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric
    Height 550mm 550mm 550mm 550mm 550mm 550mm
    Finish White White White White White White
    Pipe Centres 440mm 580mm 790mm 1000mm 1210mm 1420mm
    Wall to Pipe Centres 68mm 68mm 68mm 68mm 68mm 68mm
    Wall Distance 113mm 113mm 113mm 113mm 113mm 113mm
    Tube Quantity 6 8 11 14 17 20
    BTU - Delta-50 2070 2761 3796 4833 5868 6904
    Watts - Delta-50 607 810 1113 1417 1721 2025
    BTU - Delta-60 2650 3534 4859 6186 7511 8837
    Watts - Delta-60 777 1036 1425 1814 2203 2592
    MFC RND-CNV05044W RND-CNV05058W RND-CNV05079W RND-CNV05100W RND-CNV05121W RND-CNV05142W
  • Specification For Anthracite Radiator
    Width 440mm 580mm 790mm 1000mm 1210mm 1420mm
    Fuel Type Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric Central Heating/Dual Fuel/Electric
    Height 550mm 550mm 550mm 550mm 550mm 550mm
    Finish Anthracite Anthracite Anthracite Anthracite Anthracite Anthracite
    Pipe Centres 440mm 580mm 790mm 1000mm 1210mm 1420mm
    Wall to Pipe Centres 68mm 68mm 68mm 68mm 68mm 68mm
    Wall Distance 113mm 113mm 113mm 113mm 113mm 113mm
    Tube Quantity 6 8 11 14 17 20
    BTU - Delta-50 2070 2761 3796 4833 5868 6904
    Watts - Delta-50 607 810 1113 1417 1721 2025
    BTU - Delta-60 2650 3534 4859 6186 7511 8837
    Watts - Delta-60 777 1036 1425 1814 2203 2592
    MFC RND-CNV05044A RND-CNV05058A RND-CNV05079A RND-CNV05100A RND-CNV05121A RND-CNV05142A
  • Specification For Heating Elements
    Variants Finish MFC
    Standard Heating Element Chrome ELM/S
    - - -
    On/Off Touch Element Chrome ELMOOT-C
    On/Off Touch Element Black ELMOOT-BL
    On/Off Touch Element Anthracite ELMOOT-A
    - - -
    LST Mini Round Thermostatic Element Chrome ELMMRNLST-C
    LST Mini Round Thermostatic Element Black ELMMRNLST-BL
    LST Mini Round Thermostatic Element Anthracite ELMMRNLST-A
    LST Mini Round Thermostatic Element White ELMMRNLST-W
    - - -
    Mini Round Thermostatic Element Chrome ELMMRNC
    Mini Round Thermostatic Element Black ELMMRNK
    Mini Round Thermostatic Element Anthracite ELMMRNA
    Mini Round Thermostatic Element White ELMMRNW
    - - -
    Touch Thermostatic Heating Element Chrome ELMTCH-C
    Touch Thermostatic Heating Element Anthracite ELMTCH-A
    Touch Thermostatic Heating Element Brushed Brass ELMTCH-BB
    - - -
    LST Weekly Thermostatic Element Chrome ELMWKYLST-C
    LST Weekly Thermostatic Element Black ELMWKYLST-BL
    LST Weekly Thermostatic Element Anthracite ELMWKYLST-A
    LST Weekly Thermostatic Element White ELMWKYLST-W
    - - -
    Weekly Thermostatic Element Chrome ELMWKYC
    Weekly Thermostatic Element Black ELMWKYK
    Weekly Thermostatic Element Anthracite ELMWKYA
    Weekly Thermostatic Element White ELMWKYW
    - - -
    Wireless Programmable Thermostat White ACC-WPRT7RF
    - - -
    Square Thermostatic Wifi Element Chrome ELM-SQR
  • Specification For Accessories
    TYPE Finish MFC
    T-Piece - For Dual Fuel Only Chrome ACCS/TP
    T-Piece - For Dual Fuel Only Anthracite ACCS/TPA
    T-Piece - For Dual Fuel Only White ACCS/TPW
    T-Piece - For Dual Fuel Only Brushed Brass ACCS/TPG
    T-Piece - For Dual Fuel Only Brushed Gun Metal ACCS/TPM
    - - -
    Liquid Filling For Electric Only - A/FILLING1
