Nuie Piazza 500 x 840mm Square Flat Towel Radiator
Technical drawing 72708 / HLA82
Additional image of Premier HLA82
Additional image of Nuie Piazza 500 x 840mm Square Flat Towel Radiator

Nuie Piazza 500 x 840mm Square Flat Towel Radiator

Nuie Logo
Available Finishes: Anthracite / Brushed Brass
No Rating No Rating Write a Review
Rate This:
MFC Code : HLA82
Product Code : 72708
Delivery: £34.95
£180.00
RRP : £450.00
Finishes Available

OP-209915 - Anthracite

qty :
  • Dimension: 500mm (50cm) x  30mm (3cm) [Width x Depth]
  • Height 840mm (84cm)
  • Modern design with a square profile
Read More About the Product
Questions Ask Technical Question?
Reviews Write a Review
Check Availability 5-7 Working Days Apprx

About This Product

  • Dimension: 500mm (50cm) x  30mm (3cm) [Width x Depth]
  • Height 840mm (84cm)
  • Modern design with a square profile
  • Made using steel
  • Comes with fixing screws
  • Maximum Projection from Wall: 95mm (9.5cm)
  • Wall to the centre of tappings: 200mm (20cm)
  • All tappings are 1/2" British Standard Pipe
  • Pipe Centres: 450mm (45cm)
  • Bracket included
  • Number Of Heat Settings: 1
  • Type Of Heat: Water
  • Number Of Sections/Panels 8
  • IP Rating: Ip64 Ingress Protection
  • CE, RoHS and WEEE Certified product
  • Suitable for wall-mounted installation
  • Valves and elements are not included
  • Add a stylish feature to any room
  • After installing any new radiators when refilling the system it is recommended a suitable inhibitor is used
  • We recommend pipework is not installed until receipt of the radiator or heated towel rail
  • Download the Data Sheet and Mounting Instruction PDF File from the Technical Info Section
  • Technical drawing available for more technical details
  • Guarantee: 3-years from Nuie against manufacturing defects.
  • Details For Anthracite Finish:
  • BTU: 30 Deg. C - 744, 50 Deg. C - 683, 60 Deg. C - 1727
  • Thermal Outputs (Watts): 30 Deg. C - 217, 50 Deg. C - 405, 60 Deg. C - 506
  • Details For Brushed Brass Finish:
  • BTU: 30 Deg. C - 543, 50 Deg. C - 1021, 60 Deg. C - 1280
  • Thermal Outputs (Watts): 30 Deg. C - 159, 50 Deg. C - 299, 60 Deg. C - 375
  • Available Optional Product
  • Choice of different finishes anthracite and brushed brass
  • Compatible radiator valve

Information Breakdown

Colour Anthracite
Warranty/Guarantee 3 Years
Theme Modern
Material Steel
Weight In Kg 8.4
Width 500
Projection (Depth) 30
Height 840
Compliance/Approvals/Standard CE | RoHS | WEEE
Orientation Vertical
BTU Output 30° 744 | 50° - 683
Watts 30° - 217 | 50° - 405
Tapping / Pipe Centres 200
Valves Included Sold Separately
Fuel Type Central Heating
Brackets Included Yes
No. of Sections 8
Installation Type Wall Mounted
Compatible Valves

Technical Info

Nuie Piazza 500 x 840mm Square Flat Towel Radiator

Download Data Sheet PDF

Download Mounting Instruction PDF
