Hudson Reed Elgin 550 x 1080mm Designer Radiator

Hudson Reed Logo
Finish Available: Anthracite / Chrome
No Rating No Rating Write a Review
Rate This:
MFC Code : HLA36
Product Code : 29805
Delivery: £34.95
£239.75
RRP : £620.00
Finishes Available

OP-146277 - Anthracite


qty :

  • Choice of finishes: Anthracite and chrome - [Optional]
  • Dimensions: Width 550mm (55cm) x Height 1080mm (108cm)
  • Material: Steel
Read More About the Product
Check Availability 5-7 Working Days Apprx
Heating Element
Hudson Reed Heating Element

Excellent Heat output with an attractive Chrome finish and 12 month of guarantee. Please Note: Image Shown is for illustration purpose only.



About This Product

  • Choice of finishes: Anthracite and chrome - [Optional]
  • Dimensions: Width 550mm (55cm) x Height 1080mm (108cm)
  • Material: Steel
  • Installation type: Wall mounted
  • Supplied with fixing screws
  • Pipe center for valves : 50mm (5cm)
  • Number Of Sections/Panels: 12
  • Number of Heat setting: 1
  • Type of heat: water
  • Comes with a 1/2 inch BSP
  • It is recommended that the new installed radiator is refiled with a suitable inhibitor
  • Valves and Heating elements are not included
  • For fitting instruction download PDF from Technical tab
  • Refer technical drawing for complete dimensions details
  • Guarantee: 5 years from Hudson Reed against manufacturing defects.
  • Optional Products:
  • Compatible Valve
  • Heating element
  • Specifications For Anthracite Finish:
  • RAL NO: 7016
  • Heat Output at 60°C: BTU/hr 2122 and Watts 622
  • Heat Output at 50°C: BTU/hr 1706 and Watts 500
  • Heat Output at 30°C: BTU/hr 864 and Watts 253
  • Projection from the wall: 50mm (5cm)
  • Specifications For Chrome Finish:
  • Heat Output at 60°C: BTU/hr 1453 and Watts 410
  • Heat Output at 50°C: BTU/hr 1147 and Watts 336
  • Heat Output at 30°C: BTU/hr 581 and Watts 170
  • Projection from the wall: 110mm (11cm).
Note: Hudson Reed recommends that the pipework should not be done until the heated towel rail is receipt. Dimension are subjected to minor deviation.

Information Breakdown

Colour Anthracite
Warranty/Guarantee 5 Years
Width 550
Projection (Depth) 50
Orientation Vertical
BTU Output @ 60°C 2122, @ 50°C 1706/hr And @ 30°C 864/h
Watts @ 60°C 622, @ 50°C 500 And And @ 30°C 253
Tapping / Pipe Centres 50
Valves Included Sold Separately
Design Modern
Installation Type Wall Mounted

Technical Info


PRODUCT VARIATIONS INFO & MFC CODE
Available Finishes :
  • Anthracite - HLA36
  • Chrome - HL336.
