Trojan Elite Edge Single Ended Fully Encapsulated Baseboard Bath

Trojan Elite Edge Single Ended Fully Encapsulated Baseboard Bath

Name: Trojan Elite Edge Single Ended Fully Encapsulated Baseboard Bath
Brand: Trojan Baths
SKU: B002496
Price: 232.22 GBP
Availability: InStock

Available Width: 700mm / 750mm / 800mm

No Rating

Write a Review

Rate This:

MFC Code : B002496

Product Code : 72631

Delivery: £34.95

£232.22

RRP : £600.00

Other Variation Available

1700 x 700mm
1700 x 750mm
1800 x 800mm

OP-206327 - 1700 x 700mm

qty :

Made using lucite acrylic sheet
Made in the UK from 100% sanitary grade cast acrylic
Comes in white finish

About This Product

Made using lucite acrylic sheet
Made in the UK from 100% sanitary grade cast acrylic
Comes in white finish
Dimension: Depth 400mm (40cm) x Height 510mm (51cm)
Encapsulated baseboard routed and shaped to cover the full base of the bath, including around the plug hole
Comes with timber frame including 4mm plywood tap platform to offer rim support and fixing points for installation kits
Material and product standards: EN263, EN198, CE EN 14516:2015 CL.1 PH, FSC TT-COC-003576
Supplied with bath fittings as standard
Pair of tubular cradles supplied to provide support to the bath
Comes undrilled - can be drilled for bath-mounted taps
The image shown is for illustration purposes only
Waste, Overflow showed in the image are not included
For complete size details please refer technical drawing
Guarantee : 25 years from Trojan
Available Optional Product
Three different sizes
Bath front and end panel
Bath waste

Information Breakdown

Colour	White
Country of Origin	UK
Warranty/Guarantee	25 Years
Theme	Modern
No. of Bathers	1
Material	Lucite Acrylic Sheet
Tap Holes	Un-Drilled
Waste Included	Sold Separately
Front Panel Included	Sold Separately
End Panel Included	Sold Separately
Feets Included	Yes
Height Including Feet or Panel	510
Tub Depth	Internal - 400, External - 380
External Length	1700
External Width	700
Internal Bottom Length	1260
Internal Bottom Width	490
Internal Top Length	1515
Internal Top Width	570
Height of Rim	40

PRODUCT VARIATIONS INFO & MFC CODE

Details Of Bath

Sizes MFC

1700 x 700mm B002496

1700 x 750mm B002497

1800 x 800mm B002498
