Nuie Lorica 500mm Wide Brushed Brass Round Straight Towel Radiator

Name: Nuie Lorica 500mm Wide Brushed Brass Round Straight Towel Radiator
Brand: Nuie
SKU: MTY803
Price: 120 GBP
Availability: InStock

Available Height: 800mm / 1200mm

No Rating

Write a Review

Rate This:

MFC Code : MTY803

Product Code : 72707

Delivery: £34.95

£120.00

RRP : £300.00

Other Variation Available

800 [mm]
1200 [mm]

OP-209734 - 800 [mm]

qty :

Manufactured using steel
Width 500mm (50cm)
Finish: Brushed brass

About This Product

Manufactured using steel
Width 500mm (50cm)
Finish: Brushed brass
Maximum Projection from Wall: 95mm (9.5cm)
Wall to Centre of Tapping: 200mm (20cm)
Pipe Centres: 450mm (45cm)
Come complete with fixing screws
Type Of Heat: Water
Number Of Heat Settings: 1
All tappings are 1/2" British Standard Pipe
CE, RoHS and WEEE Certified product
IP Rating: Ip64 Ingress protection
Valves and elements are not included
Add a stylish feature to any room
Suitable for use with heating elements
After installing any new radiators when refilling the system it is recommended a suitable inhibitor is used
We recommend pipework is not installed until receipt of the radiator or heated towel rail
Download the Data Sheet and Mounting Instruction PDF File from the Technical Info Section
Technical drawing available for more technical details
Guarantee: 3 Years from Nuie against manufacturing defects
Specification For 800mm (80cm) High:
Height: 800mm (80cm)
BTU: 30 Deg. C - 458, 50 Deg. C - 850, 60 Deg. C - 1062
WATTS: 30 Deg. C - 134, 50 Deg. C - 249, 60 Deg. C - 311
Number Of Sections/Panels: 10
Specification For 1200mm (120cm) High:
Height: 1200mm (120cm)
BTU: 30 Deg. C - 748, 50 Deg. C - 1406, 60 Deg. C - 1765
WATTS: 30 Deg. C - 134, 50 Deg. C - 412, 60 Deg. C - 517
Number Of Sections/Panels: 17
Available Optional Product
Choice of height 800mm (80cm) and 1200mm (120cm)
Valves

Information Breakdown

Colour	Brushed Brass
Warranty/Guarantee	3 Years
Theme	Modern
Material	Steel,Steel,Steel
Weight In Kg	3.4
Width	500
Projection (Depth)	95
Height	800
Compliance/Approvals/Standard	CE, RoHS, WEEE
Orientation	Vertical
BTU Output	30 Deg. C - 458 \| 50 Deg. C - 850
Watts	30 Deg. C - 134 \| 50 Deg. C - 249
Tapping / Pipe Centres	200
Valves Included	Sold Separately
Brackets Included	Yes
No. of Sections	10
Installation Type	Wall Mounted

Compatible Valves

Technical Info

Download Data Sheet PDF

Download Mounting Instruction PDF

PRODUCT VARIATIONS INFO & MFC CODE

Available Height

Height MFC

800mm MTY803

1200mm MTY805
